As a tattoo artist, you may need a camera for taking photographs or recording videos during a process of your creation. You may use a mobile phone, but you might be interrupted by phone calls or messages while recording; you might be thinking about using a DSLR camera, but it won’t record more than an hour unless you have to pause your work while it’s charging. What you really need is a Time Lapse Camera that can record your entire creation process without being worry about battery life. That is TLC120, the Time Lapse Camera.
3
| 1.Battery Low |
2.Power Status |
3.Bluetooth Status |
| 4.1/4”Tripod mount thread |
5.1/4”Tripod mount screw |
6.Power |
| 7.2 AAA Batteries |
8.Battery cover |
9.30° angle indicator |
|
|
|
|
TLC120 Easy Set Up |
 |
 |
 |
| 1.Place it |
2.Connect the app |
3.Start Recording |
|
| |
| Other areas |
 |
 |
 |
| Remodelling |
Sculpture |
Hair styling |
|
| |
One button operation, create your own time lapse video under any light condition! |
| High performance HDR video sensor with Pixel Size 4.2μm, no complicated set up, it helps capture great shots/time lapse videos with high contrast under any light condition! |
 |
 |
 |
 |
| Ipx4 splash and weather resistant |
Bluetooth |
SD card local storage |
112° wide angle |
|
| |
Powerful Brinno APP |
| Download the Brinno app allows you to control your time lapse camera. The powerful Brinno app includes settings that you can play around with. How to properly set brightness and contrast? We are here to help. |
|
| |
|
Time Lapse Your Process, Light Up Your Film |
|
| Video editing allows you to tell a great story even greater. It is the key to blend images and sounds to make your audiences feel emotionally connected and amazed by your work. Create your video story by your own flow. |
|
 |
|
| |
|
| Video Editing Demonstration |
|
 |
|
| |
|
| Specification |
| Product name |
Wi-Fi TimeLapse Camera TLC120 |
| Model No. |
TLC120 |
| Splashproof |
IPX4 |
| Image Sensor |
1/3“ HDR Image Sensor
Dynamic Range 115 db
Pixel Size 4.2μm
Sensitivity3650mV/lux-sec (Ultra good low light quality) |
| Optics Lens |
Low Distortion Fixed Aspherical Lens
Aperture: F2.0
Field of View: 112°
FocalLength 19 mm (35mm equivalent) |
| Video Format |
AVI(1280x720 Resolution) |
| Shooting Setting |
Scene:Daylight, Twilight, Night, Moon, Star
White Balance: Auto, Day, Shade, Cloudy, Fluorescent Light (Cool), Fluorescent Light (Warm), Tungsten Light
Custom Image: Exposure, Saturation, Contrast, Sharpness |
| Memory Storage |
SD / SDHC Card (Supported up to 32 GB) |
| Power Source |
Li-Po Rechargeable Battery (1500mAh)DC IN: 5V (Micro USB Connector) |
| Battery Life |
1.5 days with a 2 seconds time interval20 days with a 5 minutes time interval |
| Wireless |
Wi-Fi (802.11 b/g/n), Bluetooth 4.0 (BLE) |
| Brinno App |
Android 4.4 / iOS 7.0 above |
| Camera Size |
60x60x33.5 mm |
| Camera Weight |
101 g |
| Color |
Black, Orange |
| Package contents |
HDR TimeLapse Camera (TLC120)8GB SD cardMicro USB cableQuick guide |
| Operation temperature |
0-40°C |
|
| Battery Life Chart |
| App Shutter Mode |
|
Camera Shutter Mode |
| Time Interval |
Frames |
Days |
| 1 sec |
66375 |
1 |
| 2 sec |
62471 |
1 |
| 5 sec |
53100 |
3 |
| 10 sec |
42480 |
5 |
| 20 sec |
30343 |
7 |
| 30 sec |
23600 |
8 |
| 1 min |
14160 |
10 |
| 5 min |
3371 |
12 |
| 10 min |
1727 |
12 |
| 1 hr |
294 |
12 |
| 4 hr |
74 |
12 |
| 24 hr |
12 |
12 |
|
|
| Time Interval |
Frames |
Days |
| 1 sec |
66375 |
1 |
| 2 sec |
64130 |
1 |
| 5 sec |
58224 |
3 |
| 10 sec |
50475 |
6 |
| 20 sec |
39865 |
9 |
| 30 sec |
32940 |
11 |
| 1 min |
21656 |
15 |
| 5 min |
5789 |
20 |
| 10 min |
3022 |
21 |
| 1 hr |
523 |
22 |
| 4 hr |
131 |
22 |
| 24 hr |
22 |
22 |
|
|
- The battery life chart demonstrates only when video recording.
- Battery power consumption depends on factors such as the process of preview wait, file transfer, network configuration, and many other factors; actual results will vary.
|
| Comparison |
| Model |
TLC200 |
TLC200 Pro |
TLC120 |
| Viewfinder |
1.44 LCD |
1.44" LCD |
- |
| Image sensor |
1.3 MP |
1.3 MP |
1.3 MP |
| Resolution |
1280 x 720 (16:9) |
1280 x 720 (16:9) |
1280 x 720 (16:9) |
| Aperture |
f/2.8 |
f/2.0 |
f/2.8 |
| Focal length (mm) |
36 |
19 (35mm equivalent) |
19 (35mm equivalent) |
| Field of view |
59 degree |
112° (720P) |
112° (720P) |
| 112° (720P) |
- |
✓ |
✓ |
| Aspherical lens |
- |
✓ |
✓ |
| Interchangeable CS mount lens |
- |
✓ |
- |
| HDR video |
- |
✓ |
✓ |
| Scene setting |
- |
✓ |
✓ |
| White balance setting |
- |
✓ |
✓ |
| Micro USB output |
- |
✓ |
✓ |
| Webcam function |
- |
✓ |
✓ |
| Wi-Fi |
- |
- |
Wi-Fi (802.11 b/g) |
| Bluetooth |
- |
- |
BLE 4.0 |
| Brinno APP |
- |
- |
Android 4.4/ iOS 7.0 above |
| Time interval |
0.5 sec, 1 sec-24 hrs |
0.3 sec, 1 sec-24 hrs |
0.3 sec, 1 sec-24 hrs |
| Battery life |
270,000 photos |
240,000 photos |
66,000 photos |
| Storage media |
SD/SDHC card |
SD/SDHC card |
SD/SDHC card |
| Media included |
4GB |
4GB |
8GB |
| Maximum storage capacity |
32GB |
32GB |
32GB |
| Video format |
AVI |
AVI |
AVI |
| Weather resistant |
With optional housing ATH110 |
With optional housing ATH120 |
IPX4 |
| Stop Motion video |
With optional shutter release cable |
With optional shutter release cable |
- |
| Still images (JPEG, 1280 x 720) |
With optional shutter release cable |
With optional shutter release cable |
- |
| Batteries required |
4 AA (included) |
4 AA (included) |
Li-Po rechargeable Battery,1500mAh |
| External power |
5V micro USB |
5V micro USB |
5V micro USB |
| Size (WxHxD) |
64 x 46x 106 mm |
54 x52x 107 mm |
60 x60 x 33.5 mm |
| Weight |
120 g |
140 g |
101 g |
| Color |
Green/ White |
Black |
Black/ orange |
|
